Hyster has right sized the electric high-capacity solution for performance and efficiency with an optimal 350V system providing the ICE-like performance expected without the additional costs and complexity for the higher voltage systems in competitive offerings. Additionally, Hyster offers the widest configuration of lithium-ion battery modules across the series that is configurable to any application needs and scalable to meet future business needs.
The integrated lithium-ion battery solution produces zero tailpipe emissions and allows for fast charging times and opportunity charging during break times.
| Model | Load Capacity | Load Center | Lift Height | Turning Radius | Battery Capacity Voltage | Overall Width | Weight | Engine Type |
|---|---|---|---|---|---|---|---|---|
| J230XD | 23000lbs | 24in | 147 | 162 | 350 / (192 / 384 ) | 98 | 31398 | Electric |
| J250XD | 25000lbs | 24in | 147 | 162 | 350 / (192 / 384 ) | 98 | 32611 | Electric |
| J280XD | 28000lbs | 24in | 147 | 162 | 350 / (192 / 384 ) | 98 | 34374 | Electric |
