Hyster UTL models are equipped with a maintenance-free integrated lithium-ion battery with charge port that is designed into the forklift direct from the factory. AC traction and lifting motors with electronic control as well as maintenance-free oil-immersed brakes and a regenerative braking system provide for smooth performance. Multiple performance modes are selectable through the dash display.
| Model | Load Capacity | Load Center | Lift Height | Turning Radius | Battery Capacity Voltage | Weight |
|---|---|---|---|---|---|---|
| J30UT | 3000lbs | 24in | 119.4 | 77.4 | Lead acid or thin plate pure lead | 6505 |
| J35UTL | 3500lbs | 24in | 119.4 | 77.4 | Lead acid or thin plate pure lead | 7120 |
| J35UT | 3500lbs | 24in | 119.4 | 77.4 | Lead acid or thin plate pure lead | 7120 |
| J40UT | 4000lbs | 24in | 119.6 | 81.9 | Lead acid or thin plate pure lead | 8665 |
| J50UTL | 5000lbs | 24in | 119.6 | 81.9 | Lead acid or thin plate pure lead | 9040 |
| J70UT | 7000lbs | 24in | 120.0 | 94.7 | Lead acid or thin plate pure lead | 11905 |
