Hyster RS46 Reach Stacker Container Handler

Hyster RS46 Reach Stacker Container Handler Information

Models

RS46

Capacity

30865-101413lbs

A wide range of configurations and options provide an excellent match to many different applications, which may include intermodal container handling, barge handling, container tipping, steel or wind operations to name just a few.

Innovative Hyster Reach Stackers are available in a wide range of configurations and options providing unprecedented flexibility to perform tasks in many different applications including 2nd rail handling, container dumping, windmill blade and tower handling, steel handling and barge handling. A Hyster ReachStacker can be equipped with a toolchanger attachment giving the operator the ability to more easily and quickly switch between different attachments (ie: slab tongs & magnets, c-hooks, pipe clamps) and enable a leaner, more productive fleet for steel operations.

Model	Load Capacity	Load Center	Lift Height	Turning Radius	Overall Width	Weight	Engine Type	Transmission	Stacking Height 1st Row	Stacking Height 2nd Row	Stacking Height 3rd Row	Load Capacity 1st Row	Load Capacity 2nd Row	Load Capacity 3rd Row
RS46-33XD/62	101413lbs	73in	601	331	165	159174	Cummins QSL 9L Diesel	Dana S.O.H TE 32	5 / 5	4 / 5	3 / 4	101	73	37
RS46-36XD/62	101413lbs	73in	605	362	165	174827	Cummins QSL 9L Diesel	Dana S.O.H TE 32	5 / 5	4 / 5	3 / 4	101	79	42
RS46-41XD/67	101413lbs	73in	605	366	165	182102	Cummins QSL 9L Diesel	Dana S.O.H TE 32	5 / 5	4 / 5	3 / 4	101	90	91
RS46-41XD/62S	101413lbs	73in	605	362	165	184306	Cummins QSL 9L Diesel	Dana S.O.H TE 32	5 / 5	4 / 5	3 / 4	101	90	62
RS46-41XD/67S	101413lbs	73in	605	366	165	186511	Cummins QSL 9L Diesel	Dana S.O.H TE 32	5 / 5	4 / 5	3 / 4	101	90	66
RS46-29XD/62	101413lbs	73in	601	331	165	151017	Cummins QSL 9L Diesel	Dana S.O.H TE 32	5 / 5	4 / 5	3 / 4	101	64	31
RS46-41XD/75S	101413lbs	73in	599	429	165	186621	Cummins QSL 9L Diesel	Dana S.O.H TE 32	5 / 5	4 / 5	3 / 4	101	90	75
